IGBT POWER SUPPLY, 96 KW, 0 TO 16 VDC, 6000 AMPS, P/N 6138C2

Send us an email for a Free Quote.

quote@cehco.com

Our engineers will respond within the hour

Description:

MSA Tower switch mode (IGBT) rectifier, air-cooled:

  • Modular “building block” design is easily expandable
  • < 3% ripple through full output range for consistent process results
  • High efficiency (>90%) and power factor through the full output range
  • Smaller and lighter than SCR or power stat rectifiers
  • 100% duty cycle (rated for 100% output 24/7)
  • Corrosion resistant, e-coat primer with powder coat top coat, steel cabinet
  • Steel base and removable side panels
  • All connections accessible from outside, making maintenance easy
  • To remove/add a module: simply loosen screw and cable connections (disassembly of module stack is not necessary)
  • DC output through copper bus bars in the back
  • All power conductors are made exclusively out of copper
  • Current and voltage adjustable from 1% to 100% with wear-free power semiconductors
  • Complete modular rectifier concept designed as a ready-to-go system
  • Switch mode modules operated in parallel to achieve specified output
  • Each module housed in a e-coat primed, powder coated enclosure for maximum corrosion protection
  • Design allows for quick and easy replacement of the modules if needed
  • 0-10 V analog interface for automatic line control systems

Integrated power module features:

  • System consists of one control module, plus one to five power modules
  • High efficiency, 19” rack mount switch mode power modules (up to 25kW each) operating in parallel
  • Maximum of 5 modules, up to 125kW (up to 7500A depending on VDC)
  • Maximum output voltage (depending on model chosen) 45 VDC
  • EMC filter to minimize EMC noise to the power grid
  • Fully electronic current and voltage control loop
  • Highly efficient control and rectification system with galvanic isolation between AC input and DC output

Air cooling system:

  • Cooling air flow: air intakes on the bottom of each module and exhausts out the rear of each module
  • Minimal cooling air required: variable speed, thermostatically controlled fans
  • All sensitive electronics are sealed from the cooling air
  • Air is directed only to the heat sinks cooling the power components
  • All circuit boards are conformal coated for additional corrosion protection
  • Thoughtful design ensures exceptional service life

Main Components:

  • Circuit breaker with overcurrent trip function
  • EMC filter to reduce noise back to the power grid
  • Electronics for constant current and voltage control
  • Power distribution panel

Protection Devices:

  • Ultra-fast DC over-current protection
  • DC short-circuit current limitation
  • Over-temperature protection (with indication through potential-free contact)

Controls Interface:

  • Set-point adjustment for Volts & Amps: 0 – 10Vdc
  • Voltage feedback values: 0 – Volts actual: 0 – 10Vdc
  • Current feedback values: 0 – Amps actual: 0 – 10Vdc
  • On/Off via potential-free contact (Customer)
  • Fault Feedback (Customer)

The photo of the three power modules is shown below:





Technical Data:

  • Input voltage: 480 V (±10 %), 3 Ph, 50-60 Hz + GND
  • Input current: 143 A
  • Power factor: > 0.95
  • DC output voltage: 16 V
  • DC output current: 6000 A
  • Duty factor: 100%
  • Ripple: 2 to 3% (through entire power curve)
  • Adjustment: 0 – 100% current and voltage
  • Control: constant current and voltage control
  • Control accuracy: < 1%
  • Cooling: Forced air cooled
  • Ambient temperature: Up to 104° F, Up to 122° F at de-rated power
  • Site altitude: Up to 3280 feet above sea level
  • Rectifier Dimensions: 20 W x 24.5 D x 55 H inches
  • Power Panel Dimensions: 13 W x 4 D x 17 H inches
  • Weight: 565 lbs.
  • Pedestal Dimensions: 21.3 W x 21.7 D x 4 H inches

Our stainless steel pedestal for the MSA Tower rectifiers comes standard and elevates the rectifier off the floor (+ 4 inches). It helps to prevent liquid or dust from entering the rectifier from the floor.

To discuss your requirements, please contact us 714-624-4740, or send us an email at quote@cehco.com
